Talyrond 400H Series Cylindrometer

The new Talyrond 400H roundness measuring instrument uses rotary, vertical and horizontal measuring datums to replicate the movement of the machine tool to accurately contour the shape of the workpiece. This high-precision simulation of the cutter path gives you precise control over the production process.

Inquiry Online
Sales Manager: Mr Li
Cell Phone:18621180929
Email: Tim@labgaegs.com
Working time: 09:00-17:45

Talyrond 400H New concept of roundness measurement


The Talyrond 400H series is hard to surpass in the field of speed and position control, and is ideal for measuring large volume precision parts.

High-precision simulation of manufacturing processes

The new Talyrond 400H roundness measuring instrument uses rotary, vertical and horizontal measuring datums to replicate the movement of the machine tool to accurately contour the shape of the workpiece. This high-precision simulation of the cutter path gives you precise control over the production process.

High reproducibility of measurement results

Decades of experience, precision machining expertise and finite element analysis (FEA) optimization design combine to produce low-noise, nearly perfect mechanical shafts. The function is further enhanced through the use of traceable standards and special algorithms to effectively eliminate the impact of the instrument on the measurement results.

Overview of Talyrond 400H Series Cylindrometer

? Optional automatic arm azimuth / steering mechanism
? Automatic sensor calibration
? High-precision air spindle +/- 0.015 um
? Sensor resolution 0.3 nm
? Vertical linear units 300 mm and 500 mm


Unparalleled measurement capabilities of Talyrond 400H Series Cylindrometer

Multi-purpose machine

High-precision simulation of the manufacturing process, enabling all measurements to be performed on one instrument

Roughness

High-resolution sensors and low noise on each axis ensure straight or circumferential surface roughness measurement.
Talyrond 400H straight or circumferential surface roughness measurement

Roundness

Friction-free air-bearing spindle and high-precision column ensure the accuracy of roundness, cylindricality and straightness measurement.
Friction-free air-bearing spindle and high-precision column

Profile

The unique calibration technology enables the instrument to measure radius, angle, height, length and distance.
Talyrond 400H measures radius, angle, height, length and distance

Cylindrical mapping

The precise control and low noise of all axes enables in-depth analysis of cylindrical parts such as wear scars and material volumes.
in-depth analysis of cylindrical parts

Cam and piston

A high-precision encoder and linearity of all axes ensure measurement of non-circular components such as cams and pistons.
measurement of non-circular components
